Modular Digital Advertising Display Screens , Hd LED Video Wall 104X104 P

  • 1
  • 2
  • 3

Brand Name : BST

Model Number : IRA-3

Certification : CE,RoHs, FCC, ISO9001

Place of Origin : Shenzhen, China

MOQ : 1 pc/ 1 sqm.

Price : Negotiation

Payment Terms : L/C, T/T, Western Union

Supply Ability : 5000sq.meter / Month

Delivery Time : 10-20 days after receive payment

Packaging Details : Flight case : 8 panels in one Case

Physical Pitch : 3.91

Pixel Configuration : SMD2121

Module Dimensions (WXH)(mm) : 250X250

Physical Resolution of Module(WXH) : 64X64

Panel Material : Die-Casting Aluminum

Single Cabinet Weight : 8/14kg/panel

Contact Now

Modular Digital Advertising Display Screens , Hd LED Video Wall 104X104 P



Digital Advertising Display Screens Parameters

Digital Advertising Display Screens SPECIFICATION
IRA-2X IRA-2 IRA-3 IRA-4
Physical Pitch 2.6mm 2.97 3.91 4.81
Pixel Configuration SMD2121 SMD2121 SMD2121 SMD2121
Pixel Density 147,456 pixels/sqm 112,896 pixels/sqm 65,536 pixels/sqm 43,264 pixels/sqm
Module Dimensions
(WXH)(mm)		 250X250 250X250 250X250 250X250
Panel Dimensions(mm) 500X500X75 /
500X1000X75		 500X500X75 /
500X1000X75		 500X500X75 /
500X1000X75		 500X500X75 /
500X1000X75
No. of Modules Per
Panel(WXH)		 2X2/2X4 2X2/2X4 2X2/2X4 2X2/2X4
Physical Resolution
of Module(WXH)		 96X96 84X84 64X64 52X52
Physical Resolution
of Panel(WXH)		 192X192/ 192X384 168X168/ 168X336 128X128/ 128X256 104X104/ 104X208
Panel Material Die-Casting Aluminum Die-Casting Aluminum Die-Casting Aluminum Die-Casting Aluminum
Single Cabinet
Weight		 8/14kg/panel 8/14kg/panel 8/14kg/panel 8/14kg/panel
Processing 16bit 16bit 16bit 16bit
Colours 281 trillion 281 trillion 281 trillion 281 trillion
Contrast Ratio 4,000:1 4,000:1 4,000:1 4,000:1
Average Power
Consumption		 64/128 W/panel 64/128 W/panel 64/128 W/panel 64/128 W/panel
Max Power
Consumption		 192/384 W/panel 192/384 W/panel 192/384 W/panel 192/384 W/panel
Operation Temp/
Humidity		 —10℃-60℃ /10%-60% —10℃-60℃ /10%-60% —10℃-60℃ /10%-60% —10℃-60℃ /10%-60%
Storage Temp/
Humidity		 —30℃-60℃ /10%-60% —30℃-60℃ /10%-60% —30℃-60℃ /10%-60% —30℃-60℃ /10%-60%
Refresh Rate >1920Hz >1920Hz >1920Hz >1920Hz
Brightess ≥1,200nits ≥1,200nits ≥1,200nits ≥1,200nits
Horizontal Viewing
Angle		 160° 160° 160° 160°
Vertical Viewing
Angle		 140° 140° 140° 140°
Expected Lifetime 100,000Hrs 100,000Hrs 100,000Hrs 100,000Hrs
Max Stacking 20/10 20/10 20/10 20/10
Max Hanging 20/10 20/10 20/10 20/10
Servicing Front/Rear Front/Rear Front/Rear Front/Rear
IP Rationg
(Front/Rear)		 IP 40/IP21 IP 40/IP21 IP 40/IP21 IP 40/IP21
Certification CCC,CE,ETL,ROHS CCC,CE,ETL,ROHS CCC,CE,ETL,ROHS CCC,CE,ETL,ROHS

Digital Advertising Display Screens Application:

Entertainment events,Commercial advertising,Stadium perimeter, such as banks,schools, telecommunications, mobile media, night club, business establishments, customs, stadiums, studio, stock exchange centers, bus station, shopping malls, railways, airports, harbors, etc;
